When building AI agents or complex workflows, your application often makes multiple LLM calls, vector database queries, and tool calls to complete a single task. Sessions group these related requests together, letting you trace the entire agent flow from initial user input to final response in one unified view.

Why use Sessions#

Debug AI agent flows: See the entire agent workflow in one view, from initial request to final response
Track multi-step conversations: Reconstruct the complete flow of chatbot interactions and complex tasks
Analyze performance: Measure outcomes across entire interaction sequences, not just individual requests

Helicone example of a session template for monitoring and managing inputs from requests sent to your AI applications. — Example: A Session creating an outline for a book about space

Quick Start#

Add Session Headers

Include three required headers in your LLM requests:

{  "Helicone-Session-Id": "unique-session-id",  "Helicone-Session-Path": "/trace-path",   "Helicone-Session-Name": "Session Name"}

Structure Your Paths

Use path syntax to represent parent-child relationships:

"/abstract"                    // Top-level trace"/abstract/outline"           // Child trace"/abstract/outline/lesson-1"  // Grandchild trace

Make Your Request

Execute your LLM request with the session headers included:

const response = await client.chat.completions.create(  {     messages: [{ role: "user", content: "Hello" }],     model: "gpt-4o-mini"   },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/greeting",      "Helicone-Session-Name": "User Conversation"    }  });

Understanding Sessions#

What Sessions Can Track#

Sessions can group together all types of requests in your AI workflow:

LLM calls - OpenAI, Anthropic, and other model requests
Vector database queries - Embeddings, similarity searches, and retrievals
Tool calls - Function executions, API calls, and custom tools
Any logged request - Anything sent through Helicone's logging

This gives you a complete view of your AI agent's behavior, not just the LLM interactions.

Session IDs#

The session ID is a unique identifier that groups all related requests together. Think of it as a conversation thread ID.

What to use:

UUIDs (recommended): 550e8400-e29b-41d4-a716-446655440000
Unique strings: user_123_conversation_456

Why it matters:

Same ID = requests get grouped together in the dashboard
Different IDs = separate sessions, even if they're related
Reusing IDs across different workflows will mix unrelated requests

// ✅ Good - unique per conversationconst sessionId = randomUUID(); // Different for each user conversation// ❌ Bad - reuses same IDconst sessionId = "chat_session"; // All users get mixed together

Session Paths#

Paths create the hierarchy within your session, showing how requests relate to each other.

Path Naming Philosophy:

Think of session paths as conceptual groupings rather than chronological order. Requests with the same path represent the same "type" of work, even if they happen at different times.

Example: In a code review agent, all "security check" requests get the same path (/review/security) whether they happen early or late in the analysis. This lets you see patterns in the duration distribution chart - all security checks will be colored the same, showing you when they typically occur and how long they take.

Path Structure Rules:

Start with / (forward slash)
Use / to separate levels: /parent/child/grandchild
Keep names descriptive: /analyze_request/fetch_data/process_results
Group by function, not by time - same conceptual work = same path

How Hierarchy Works:

"/conversation"                    // Root level"/conversation/initial_question"   // Child of conversation  "/conversation/followup"          // Another child of conversation"/conversation/followup/clarify"  // Child of followup

Path Design Patterns:

// Workflow pattern - good for AI agents"/task""/task/research" "/task/research/web_search""/task/generate"// Conversation pattern - good for chatbots"/session""/session/question_1""/session/answer_1" "/session/question_2"// Pipeline pattern - good for data processing"/process""/process/extract""/process/transform""/process/load"

Session Names#

The session name is a high-level grouping that makes it easy to filter and organize similar types of sessions in the dashboard.

Good session names:

"Customer Support" - All support sessions use this name
"Content Generation" - All content creation sessions use this name
"Trip Planning Agent" - All trip planning workflows use this name

Purpose:

Quick filtering - Filter dashboard to show only "Customer Support" sessions
High-level organization - Group alike sessions for easy comparison
Performance analysis - Compare metrics across the same session type

Configuration Reference#

Required Headers#

Helicone-Session-Idstringrequired#

Unique identifier for the session. Use UUIDs to avoid conflicts.

Example: "550e8400-e29b-41d4-a716-446655440000"

Helicone-Session-Pathstringrequired#

Path representing the trace hierarchy using / syntax. Shows parent-child relationships.

Example: "/abstract" or "/parent/child"

Helicone-Session-Namestringrequired#

Human-readable name for the session type. Groups similar workflows together.

Example: "Course Plan" or "Customer Support"

Common Patterns#

Track a complete code generation workflow with clarifications and refinements:

import { randomUUID } from "crypto";import { OpenAI } from "openai";const client = new OpenAI({  baseURL: "https://ai-gateway.helicone.ai",  apiKey: process.env.HELICONE_API_KEY,});const sessionId = randomUUID();// Initial feature requestconst response1 = await client.chat.completions.create(  {    messages: [{ role: "user", content: "Create a React component for user authentication with email and password" }],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/request",      "Helicone-Session-Name": "Code Generation Assistant",    },  });// User asks for clarificationconst response2 = await client.chat.completions.create(  {    messages: [      { role: "user", content: "Create a React component for user authentication with email and password" },      { role: "assistant", content: response1.choices[0].message.content },      { role: "user", content: "Can you add form validation and error handling?" }    ],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/request/validation",      "Helicone-Session-Name": "Code Generation Assistant",    },  });// User requests TypeScript versionconst response3 = await client.chat.completions.create(  {    messages: [      { role: "user", content: "Convert this to TypeScript with proper interfaces" }    ],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/request/validation/typescript",      "Helicone-Session-Name": "Code Generation Assistant",    },  });

Track an automated PR review workflow with multiple analysis steps:

const sessionId = randomUUID();// Initial PR analysisconst analysis = await client.chat.completions.create(  {     messages: [{ role: "user", content: "Analyze this pull request for code quality and potential issues: [PR diff content]" }],    model: "gpt-4o-mini"   },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analysis",      "Helicone-Session-Name": "PR Review Bot",    },  });// Security checkconst securityCheck = await client.chat.completions.create(  {     messages: [{ role: "user", content: "Check for security vulnerabilities: SQL injection, XSS, authentication issues" }],    model: "gpt-4o-mini"   },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analysis/security",      "Helicone-Session-Name": "PR Review Bot",    },  });// Generate review commentsconst reviewComments = await client.chat.completions.create(  {     messages: [{ role: "user", content: "Generate constructive review comments based on analysis" }],    model: "gpt-4o-mini"   },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analysis/security/comments",      "Helicone-Session-Name": "PR Review Bot",    },  });

Track a multi-step API documentation generation workflow:

const sessionId = randomUUID();// Analyze API endpointsconst endpoints = await client.chat.completions.create(  {    messages: [{ role: "user", content: "Analyze these API routes and extract endpoint information: [code content]" }],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analyze",      "Helicone-Session-Name": "API Documentation Generator",    },  });// Generate OpenAPI specconst openApiSpec = await client.chat.completions.create(  {    messages: [      { role: "user", content: "Generate OpenAPI 3.0 specification based on these endpoints" }    ],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analyze/openapi",      "Helicone-Session-Name": "API Documentation Generator",    },  });// Create usage examplesconst examples = await client.chat.completions.create(  {    messages: [{ role: "user", content: "Create code examples for each endpoint in multiple languages" }],    model: "gpt-4o-mini",  },  {    headers: {      "Helicone-Session-Id": sessionId,      "Helicone-Session-Path": "/analyze/openapi/examples",      "Helicone-Session-Name": "API Documentation Generator",    },  });
